Sheet Metal and Custom Sheet Metal Design


  • Custom control cabinet in stainless steel

  • Designed for a customer for a particularly harsh environment

  • A full set of drawings, complete with bend lines, hole tables and DXF files for flat pattern sheet metal components. These can fed directly into computer controlled cutting and bending machines



  • The use of ‘Slot & Tab’ in sheet metal is becoming more common

  • This makes assembly quicker, reducing the need for jigs and fixtures



  • Special sheet metal corners

  • These can be flush riveted, or spot welded with no distortion to the base part

  • Models, drawings, flat patterns and DXF files supplied as standard

  • This is just one example of the sheet metal capability available
